Furnishing:
High quality and workmanship and painted
Incl. Locking block
Top link cat. 1
2x hydraulic connection
Delivery is completely assembled
Technical specifications:
Category: 1
Pin hole: 3/4″
Ball width: 1 3/4″
Min length: 20 7/8″
Max length: 31 7/8″
Stroke: 11″
Cylinder bore: 2″
Rod diameter: 1 3/16″
Hydraulic pressure max. 250 bar
Thrust: 3.5 to
Pulling force: 2.3 to
Weight about 10.35 kg
+
2 x hydraulic hose with plug and dust cover
Technical specifications:
Connection: 12-L bulkhead size 3 (usual coupling connector), 18-1.5 SW22 nipple + union
Hose designation Blue Flex SAE 100 3/8 R2AT DIN EN 853 2SN DN10 W.P.330
Operating pressure: 180 bar
Length: 75 cm
