This is a new Front, Right CV axle for a Yamaha UTV.
It will fit the following 4×4 models:
2006-2009 … Rhino 450
2004-2007 … Rhino 660
Front Right / Passenger side
*Not intended for use on lifted vehicles
Product features:
Stronger than OEM chromoly forged steel axle bar
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear and puncture resistance
Inboard CV joint spline count: 21
Outboard CV joint spline count: 27
Compressed axle length : 651 mm
Replaces Yamaha OEM # 5UG-F518G-20-00, 5UG-F518G-10-00, 5UG-F518G-00-00.
